Nginx is one of the most popular web servers in the world and is responsible for hosting some of the largest and highest-traffic sites on the internet. It is a lightweight choice that can be used as either a web server or reverse proxy.
In this guide, we’ll discuss how to install Nginx on your Ubuntu 20.04 server, adjust the firewall, manage the Nginx process, and set up server blocks for hosting more than one domain from a single server.
Simplify deploying applications with DigitalOcean App Platform. Deploy directly from GitHub in minutes.
Before you begin this guide, you should have a regular, non-root user with sudo privileges configured on your server. You can learn how to configure a regular user account by following our Initial server setup guide for Ubuntu 20.04.
You will also optionally want to have registered a domain name before completing the last steps of this tutorial. To learn more about setting up a domain name with DigitalOcean, please refer to our Introduction to DigitalOcean DNS.
When you have an account available, log in as your non-root user to begin.
Because Nginx is available in Ubuntu’s default repositories, it is possible to install it from these repositories using the apt
packaging system.
Since this is our first interaction with the apt
packaging system in this session, we will update our local package index so that we have access to the most recent package listings. Afterwards, we can install nginx
:
- sudo apt update
- sudo apt install nginx
After accepting the procedure, apt
will install Nginx and any required dependencies to your server.
Before testing Nginx, the firewall software needs to be adjusted to allow access to the service. Nginx registers itself as a service with ufw
upon installation, making it straightforward to allow Nginx access.
List the application configurations that ufw
knows how to work with by typing:
- sudo ufw app list
You should get a listing of the application profiles:
OutputAvailable applications:
Nginx Full
Nginx HTTP
Nginx HTTPS
OpenSSH
As demonstrated by the output, there are three profiles available for Nginx:
It is recommended that you enable the most restrictive profile that will still allow the traffic you’ve configured. Right now, we will only need to allow traffic on port 80.
You can enable this by typing:
- sudo ufw allow 'Nginx HTTP'
You can verify the change by typing:
- sudo ufw status
The output will indicated which HTTP traffic is allowed:
OutputStatus: active
To Action From
-- ------ ----
OpenSSH ALLOW Anywhere
Nginx HTTP ALLOW Anywhere
OpenSSH (v6) ALLOW Anywhere (v6)
Nginx HTTP (v6) ALLOW Anywhere (v6)
At the end of the installation process, Ubuntu 20.04 starts Nginx. The web server should already be up and running.
We can check with the systemd
init system to make sure the service is running by typing:
- systemctl status nginx
Output● nginx.service - A high performance web server and a reverse proxy server
Loaded: loaded (/lib/systemd/system/nginx.service; enabled; vendor preset: enabled)
Active: active (running) since Fri 2020-04-20 16:08:19 UTC; 3 days ago
Docs: man:nginx(8)
Main PID: 2369 (nginx)
Tasks: 2 (limit: 1153)
Memory: 3.5M
CGroup: /system.slice/nginx.service
├─2369 nginx: master process /usr/sbin/nginx -g daemon on; master_process on;
└─2380 nginx: worker process
As confirmed by this out, the service has started successfully. However, the best way to test this is to actually request a page from Nginx.
You can access the default Nginx landing page to confirm that the software is running properly by navigating to your server’s IP address. If you do not know your server’s IP address, you can find it by using the icanhazip.com tool, which will give you your public IP address as received from another location on the internet:
- curl -4 icanhazip.com
When you have your server’s IP address, enter it into your browser’s address bar:
http://your_server_ip
You should receive the default Nginx landing page:
If you are on this page, your server is running correctly and is ready to be managed.
Now that you have your web server up and running, let’s review some basic management commands.
To stop your web server, type:
- sudo systemctl stop nginx
To start the web server when it is stopped, type:
- sudo systemctl start nginx
To stop and then start the service again, type:
- sudo systemctl restart nginx
If you are only making configuration changes, Nginx can often reload without dropping connections. To do this, type:
- sudo systemctl reload nginx
By default, Nginx is configured to start automatically when the server boots. If this is not what you want, you can disable this behavior by typing:
- sudo systemctl disable nginx
To re-enable the service to start up at boot, you can type:
- sudo systemctl enable nginx
You have now learned basic management commands and should be ready to configure the site to host more than one domain.
When using the Nginx web server, server blocks (similar to virtual hosts in Apache) can be used to encapsulate configuration details and host more than one domain from a single server. We will set up a domain called your_domain, but you should replace this with your own domain name.
Nginx on Ubuntu 20.04 has one server block enabled by default that is configured to serve documents out of a directory at /var/www/html
. While this works well for a single site, it can become unwieldy if you are hosting multiple sites. Instead of modifying /var/www/html
, let’s create a directory structure within /var/www
for our your_domain site, leaving /var/www/html
in place as the default directory to be served if a client request doesn’t match any other sites.
Create the directory for your_domain as follows, using the -p
flag to create any necessary parent directories:
- sudo mkdir -p /var/www/your_domain/html
Next, assign ownership of the directory with the $USER
environment variable:
- sudo chown -R $USER:$USER /var/www/your_domain/html
The permissions of your web roots should be correct if you haven’t modified your umask
value, which sets default file permissions. To ensure that your permissions are correct and allow the owner to read, write, and execute the files while granting only read and execute permissions to groups and others, you can input the following command:
- sudo chmod -R 755 /var/www/your_domain
Next, create a sample index.html
page using nano
or your favorite editor:
- sudo nano /var/www/your_domain/html/index.html
Inside, add the following sample HTML:
<html>
<head>
<title>Welcome to your_domain!</title>
</head>
<body>
<h1>Success! The your_domain server block is working!</h1>
</body>
</html>
Save and close the file by pressing Ctrl+X
to exit, then when prompted to save, Y
and then Enter
.
In order for Nginx to serve this content, it’s necessary to create a server block with the correct directives. Instead of modifying the default configuration file directly, let’s make a new one at /etc/nginx/sites-available/your_domain
:
- sudo nano /etc/nginx/sites-available/your_domain
Paste in the following configuration block, which is similar to the default, but updated for our new directory and domain name:
server {
listen 80;
listen [::]:80;
root /var/www/your_domain/html;
index index.html index.htm index.nginx-debian.html;
server_name your_domain www.your_domain;
location / {
try_files $uri $uri/ =404;
}
}
Notice that we’ve updated the root
configuration to our new directory, and the server_name
to our domain name.
Next, let’s enable the file by creating a link from it to the sites-enabled
directory, which Nginx reads from during startup:
- sudo ln -s /etc/nginx/sites-available/your_domain /etc/nginx/sites-enabled/
Note: Nginx uses a common practice called symbolic links, or symlinks, to track which of your server blocks are enabled. Creating a symlink is like creating a shortcut on disk, so that you could later delete the shortcut from the sites-enabled
directory while keeping the server block in sites-available
if you wanted to enable it.
Two server blocks are now enabled and configured to respond to requests based on their listen
and server_name
directives (you can read more about how Nginx processes these directives here):
your_domain
: Will respond to requests for your_domain
and www.your_domain
.default
: Will respond to any requests on port 80 that do not match the other two blocks.To avoid a possible hash bucket memory problem that can arise from adding additional server names, it is necessary to adjust a single value in the /etc/nginx/nginx.conf
file. Open the file:
- sudo nano /etc/nginx/nginx.conf
Find the server_names_hash_bucket_size
directive and remove the #
symbol to uncomment the line. If you are using nano, you can quickly search for words in the file by pressing CTRL
and w
.
Note: Commenting out lines of code – usually by putting #
at the start of a line – is another way of disabling them without needing to actually delete them. Many configuration files ship with multiple options commented out so that they can be enabled or disabled, by toggling them between active code and documentation.
...
http {
...
server_names_hash_bucket_size 64;
...
}
...
Save and close the file when you are finished.
Next, test to make sure that there are no syntax errors in any of your Nginx files:
- sudo nginx -t
If there aren’t any problems, restart Nginx to enable your changes:
- sudo systemctl restart nginx
Nginx should now be serving your domain name. You can test this by navigating to http://your_domain
, where you should see something like this:
Now that you know how to manage the Nginx service itself, you should take a few minutes to familiarize yourself with a few important directories and files.
/var/www/html
: The actual web content, which by default only consists of the default Nginx page you saw earlier, is served out of the /var/www/html
directory. This can be changed by altering Nginx configuration files./etc/nginx
: The Nginx configuration directory. All of the Nginx configuration files reside here./etc/nginx/nginx.conf
: The main Nginx configuration file. This can be modified to make changes to the Nginx global configuration./etc/nginx/sites-available/
: The directory where per-site server blocks can be stored. Nginx will not use the configuration files found in this directory unless they are linked to the sites-enabled
directory. Typically, all server block configuration is done in this directory, and then enabled by linking to the other directory./etc/nginx/sites-enabled/
: The directory where enabled per-site server blocks are stored. Typically, these are created by linking to configuration files found in the sites-available
directory./etc/nginx/snippets
: This directory contains configuration fragments that can be included elsewhere in the Nginx configuration. Potentially repeatable configuration segments are good candidates for refactoring into snippets./var/log/nginx/access.log
: Every request to your web server is recorded in this log file unless Nginx is configured to do otherwise./var/log/nginx/error.log
: Any Nginx errors will be recorded in this log.Now that you have your web server installed, you have many options for the type of content to serve and the technologies you want to use to create a richer experience.
If you’d like to build out a more complete application stack, check out the article How To Install Linux, Nginx, MySQL, PHP (LEMP stack) on Ubuntu 20.04.
In order to set up HTTPS for your domain name with a free SSL certificate using Let’s Encrypt, you should move on to How To Secure Nginx with Let’s Encrypt on Ubuntu 20.04.
Want to easily configure a performant, secure, and stable Nginx server? Let us spin up an Nginx virtual machine for you in seconds, so you can focus on building a great application.
